Parameter:
| Model | P028HK9853-24P |
| Screen Size | 2.8 inch |
| Number of Pixel | 240RGB(H)x320(V) |
| Display area | 43.20(H)x57.60(V)mm |
| Pixel pitch | 0.180(H)x0.180(V)mm |
| Pins | 24 pins |
| Outline Dimension | 50.00x69.20x2.30mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally black |
| Viewing Direction(eye) | ALL |
| Gray inversion direction | -- |
| Display Color | 262K |
| Luminance(cd/m2) | 200 nit |
| Contrast Ratio | 1200:1 |
| Surface treatment | -- |
| Interface | 4-line SPI |
| Back-light | LED Side-light type |
| Drive IC | JD9853 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
